High density, double-conversion on-line power protection with scalable runtime.

• Primary Information

  Product Description:	APC Smart-UPS SRT 1500VA RM - UPS - 1.35 kW - 1500 VA
  Device Type:	UPS - Power Factor Correction (PFC) - rack-mountable / external
  Rack Size:	2U
  Weight:	48.5 lbs
  Input Voltage:	AC 120 V
  Output Voltage:	AC 120 V ± 2%
  Power Capacity:	1.35 kW / 1500 VA
  Input Connectors:	1 x power NEMA 5-15P
  Output connectors:	6 x power NEMA 5-15
  Battery:	Lead acid
  Run Time (Up To):	5 min at full load
  Networking:	RS-232, USB
  Included Accessories:	Temperature probe
  Color:	Black
  Dimensions (WxDxH):	17 in x 20 in x 3.3 in
  Environmental Standards:	ENERGY STAR
  Manufacturer Warranty:	3-year warranty

• General

  Device Type:	UPS - Power Factor Correction (PFC) - rack-mountable / external
  Height (Rack Units):	2U
  Color:	Black

• Power Device

  UPS Technology:	On-line
  Input Voltage:	AC 120 V
  Input Voltage Range:	AC 90 - 150 V
  Frequency Provided:	50/60 Hz ± 3Hz
  Frequency Required:	47 - 70 Hz
  Input Connectors:	1 x power NEMA 5-15P
  Power Output Connectors Details:	6 x power NEMA 5-15
  Output Voltage:	AC 120 V ± 2% - 50/60 Hz
  Power Capacity:	1.35 kW / 1500 VA
  Output Waveform:	Sinewave
  Surge Suppression:	Yes
  Surge Energy Rating:	480 Joules
  Circuit Protection:	Circuit breaker
  Efficiency:	91% at 100% Load, 90.2% at 50% Load, 86.6% at 25% Load, 90.9% at 75% Load

• Battery

  Technology:	Lead acid
  Run Time (Up To):	5 min at full load ¦ 13 min at half load
  Recharge Time:	3 hours
  Features:	Maintenance free, sealed, leak-proof

• Networking

  Remote Management Interface:

  RS-232, USB

• Expansion / Connectivity

  Interfaces:	1 x management (RS-232) - RJ-45 ¦ 1 x EPO (emergency power off) ¦ 1 x management (USB)
  Expansion Slots:	1 (total) / 1 (free) x SmartSlot

• Miscellaneous

  Included Accessories:	Temperature probe
  Cables Included:	Power cable 6 ft ¦ Serial cable - external ¦ USB cable - external
  Rack Mounting Kit:	Included
  Features:	Audible alarm, LCD display, internal bypass, LED indicators, cold-start function, firmware upgradable, automatic self-test, hot-swappable batteries, Eco-Mode, lightning protection
  Compliant Standards:	UL 1778, FCC Part 15 A, CSA C22.2 No. 107.3, IP20

• Software / System Requirements

  Software Included:

  Drivers & Utilities

• Sustainability Information

  ENERGY STAR:

  Yes

• Manufacturer Warranty

  Service & Support:

  Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years

• Environmental Parameters

  Min Operating Temperature:	32 °F
  Max Operating Temperature:	104 °F
  Humidity Range Operating:	0 - 95% (non-condensing)
  Sound Emission:	50 dBA

• Dimensions & Weight

  Width:	17 in
  Depth:	20 in
  Height:	3.3 in
  Weight:	48.5 lbs

• Dimensions & Weight (Shipping)

  Shipping Width:	23.4 in
  Shipping Depth:	29.5 in
  Shipping Height:	9.7 in
  Shipping Weight:	65.26 lbs

• Special Feature

  COO:	PHILIPPINES
  TAA compliance:	No

• UNSPSC Code:

  39121011
